Synthetic Based Drilling Fluids (SBM)

Panther SBM Invert Emulsion

Our SBM Invert Emulsion system is Panther’s synthetic-based solution for wells that demand both downhole performance and greater environmental consideration. The system uses a synthetic, environmentally acceptable liquid as the external phase and brine as the internal phase.

We customize the system to help you pursue your environmental impact goals without sacrificing the lubricity, inhibition, stability, and resistance to contaminants needed for challenging drilling conditions.

When operating conditions allow, the fluid can be recycled and reused. Our team helps you manage fluid properties and solids so you can preserve usable fluid, reduce waste, and improve the efficiency of your overall fluids program.

Support Wellbore Stability

The synthetic external phase limits water contact with reactive shale, which helps slow the hydration, swelling, and disintegration of clays.

Manage Torque and Drag

SBM typically provides high lubricity that can help reduce friction between the drillstring and the wellbore. This makes it valuable in horizontal wells, extended-reach wells, and long laterals.

Support Drilling Performance

Synthetic-based mud can provide resistance to downhole contaminants. When properly maintained, the system can also support hole cleaning and fluid-loss control as well conditions change.

Handle Elevated Temperatures

Synthetic-based systems can be formulated for high-temperature wells. The right formulation depends on the expected downhole conditions.

Reduce Toxicity and Waste

Qualifying synthetic base fluids can provide lower toxicity and improved biodegradability compared with conventional diesel-based mud. When the fluid remains within program requirements, it may also be recovered, conditioned, and reused.

When Should You Consider Synthetic-Based Mud?

SBM may be a good fit when your well requires the performance of a non-aqueous fluid system, particularly when lubricity or shale inhibition is critical.

Common applications include:

Reactive or water-sensitive shale
Horizontal and extended-reach wells
Long laterals
High-temperature wells
Complex wellbore conditions
Offshore and deepwater operations
Environmentally sensitive areas

No mud system is right for every well. Fluid selection should account for the downhole conditions and the requirements of the drilling program.

At Panther, we evaluate the full fluids program so we can recommend the right fluids at the right time.

Synthetic-based mud, oil-based mud, and water-based mud can each provide effective drilling performance. The right choice depends on the formation, well design, operating conditions, and goals of the fluids program.

FACTOR	SBM	OBM	WBM
External phase	Synthetic liquid	Diesel, mineral oil, or another petroleum-derived oil	Water or brine
Shale inhibition	Typically high	Typically high	Varies by formulation and formation
Lubricity	Typically high	Typically high	Varies by formulation
Temperature tolerance	Can be formulated for high-temperature service	Commonly used in high-temperature wells	Specialized formulations may be required
Environmental considerations	Qualifying synthetic base fluids can offer lower toxicity and improved biodegradability compared with conventional diesel-based mud	Conventional diesel-based systems may involve greater toxicity, handling, and disposal considerations	Often selected for a lower environmental footprint, depending on the complete formulation
Typical applications	Reactive shale, extended-reach, high-temperature, offshore, and deepwater wells	Reactive shale, high-temperature wells, and complex directional wells	A broad range of drilling applications

The initial cost of the mud is only one consideration. The full evaluation should also account for performance, logistics, waste handling, and total well cost.

At Panther, we help you select the system that best fits your drilling program.

How Does Panther Support Your SBM Program?

You need more than mud delivered to the wellsite. You need experienced people who can manage the system throughout drilling.

Panther provides complete drilling fluids treatment and management services. We configure, deliver, and manage complex fluid systems for all well types.

Our fluids management support includes:

Customized fluid programs
Drilling-fluid treatment and management
Experienced wellsite personnel
Fluid testing and monitoring
Treatment recommendations
Solids-control coordination
Haul-off and disposal support

Panther’s on-site fluids experts can troubleshoot drilling problems and make recommendations to the mud circulating system for effective solids control. When conditions change, we work with your team to adjust the mud system.

Why Work With Panther Fluids ?

At Panther Fluids, we combine drilling fluid systems with total fluid management to help simplify your wellsite operations.

Our services include:

Fluids management
Solids control
Haul-off and disposal
Equipment rentals

Panther can coordinate these services through a single point of contact and under one contract. This reduces the number of handoffs and gives you one team focused on your fluids program.

That is the Panther Advantage™. We handle the details of fluids management so you can stay focused on drilling the well.

Is synthetic-based mud the same as oil-based mud?

No, both are non-aqueous invert emulsion systems, but they use different external phases. SBM uses a synthetic liquid, while conventional OBM commonly uses diesel, mineral oil, or another petroleum-derived base fluid.

What is synthetic-based mud used for?

Synthetic-based mud is commonly used in wells that require high lubricity or strong shale inhibition. Applications include reactive shale, high-temperature wells, extended-reach wells, offshore operations, and deepwater drilling.

What are the benefits of synthetic drilling mud?

SBM can provide lubricity, shale inhibition, wellbore stability, contaminant resistance, and temperature tolerance. Qualifying synthetic base fluids may also provide lower toxicity and improved biodegradability compared with conventional diesel-based mud.
